Packaging machines and lines
Offer of packaging machines and lines
Our packaging machines and lines ensure the packaging of products in heat shrink foil. We manufacture automatic machines that pack your product. Group packaging of beverages and other products is a matter of course. NAPACK series machines are semi-automatic or fully automatic and are manufactured in standard steel design with KOMAXIT surface treatment in combination with plastic and stainless steel parts.
Description of packaging machines and lines
TYPE OUTPUT MACHINE TYPE
NAPACK 200 200 packages per hour poloautomat
NAPACK 300 300 packages
per hour automat
NAPACK 400 400 packages
per hour automat
NAPACK 500 500 packages
per hour automat
NAPACK 800 800 packages
per hour automat
NAPACK 1200 1200 packages
per hour automat
NAPACK 1500 2000 packages
per hour automat
More information
Options Packaging in heat shrinkable foil, foil with backing or foil with tray type backing.
Packaged products PET bottles, glass bottles, cans, other products by appointment.
Design Semi-Automatic: the operator manually inserts the bottles into the feeder. After pressing the START button, the group of bottles is inserted behind the welding bar and wrapped in foil. Passing through the hot air tunnel, the foil shrinks and fixes the wrapped bottles.
Automatic: the bottles are sorted automatically. Groups of bottles are inserted behind the welding bar by a paddle or bar feeder.
Continuous packing lines: automatic sorting of bottles. The cutting mechanism cuts the appropriate length of foil and synchronizes its movement with the bar feeder. The group of bottles is pushed by the bar feeder to the beginning of the foil cut. The end of the foil is folded in front of the group of bottles. The subsequent movement is used to wrap the bottles. Main machine parts Input conveyor, bottle feeder, foil unwinding drive, welding bar, hot air tunnel, cooling fan
